CardsSeparator (New)

Separator Card

Here’s an preview of separator card (without the border):

Preview

The Separator Card is a non-interactive visual element used to organize and group related sections of your dashboard. It displays a prominent title and an optional subtitle, making it easy to break up your dashboard into logical areas or highlight important information.

Initializer

To create a separator card in ESP-DASH v5, use the dash::SeparatorCard class.

dash::SeparatorCard separator(dashboard, "Section Title", "Optional Subtitle");

Methods

setSubtitle(const char* subtitle) / setValue(const char* value)

Set or update the separator’s subtitle (the text shown below the main title).

separator.setSubtitle("Section details or description"); // or, for compatibility: separator.setValue("Section details or description");
  • Signature: void setSubtitle(const char* subtitle) / void setValue(const char* value)
  • Parameters:
    • const char* subtitle — The subtitle or info text to display.
  • Returns: void

value()

Get the current subtitle/info text of the separator card.

const char* txt = separator.value();
  • Signature: const char* value()
  • Parameters: None
  • Returns: const char* — The current subtitle/info text.
💡

The main title is set in the initializer. Use setSubtitle or setValue to update the subtitle/info text at runtime.

Reference

// ... dash::SeparatorCard<dash::string> separator(dashboard, "My Section", "This is a subtitle"); void setup() { // ... // Set or update separator text (optional) separator.setSubtitle("Updated info for this section"); } void loop() { // ... }
